Transport, Installation and Connection
4-7
1 2
5
6
7
1 2
5
6
7
3
1 2
6
7
4
The assembly of the Ex-proof housing can be performed
in three different ways:
1. Standard
2. with quick release lock
3. with quick release lock and purge air connector
1 Swivel mount 5 EX-proof housing
2 Heating insulator 6 Cable coupling
3 Quick release
lock
7 Back view
4 Quick release
lock with purge
air connector
