SETTING THE MOTOR SLOWDOWN
1. From the MAIN MENU select PARAM (Parameters).
2. From the PARAM Sub-menu select M2 FAST TIME.
3. Set in seconds the motor's full speed running time (usually about 3 seconds less than the full stroke time).
4. Press OK.
5. If 2 motors are connected, scroll up and select M1 FAST TIME and set the full speed run time .
6. Press OK.
7. Scroll down and select SLOW SPEED.
8. Select the desired slowdown speed: 0= disabled, 1=50%, 2=33%, 3=25% (recommended)
9. Press OK.
10. Press the + and – buttons at the same time to go back to the MAIN MENU.
Prior to setting the slowdown, you must time in seconds,
how long does it take for the gate to complete a stroke
(from fully open to fully closed or viceversa).
MAIN MENU
PARAM TCA
LOGIC M1 T
RADIO M2 T
LANGUAGE M1 T SLOW
DEFAULT M2 T SLOW
AUTOSET OPEN DELAY TIME
CLS DELAY TIME
M1 FAST TIME
M2 FAST TIME
SLOW SPEED
ZONE
AUTOMATIC TORQUE ADJUSTMENT (AUTOSET)
WARNING – Gate path must be free of all traffic and obstructions. The system will
automatically open and close the gate at full torque while performing the self-
learning adjustment. Failure to do so can result in property damage and/or bodily
injury including death.
1.Close gate completely and make sure the gears are engaged.
2.From the MAIN MENU select AUTOSET.
3.Press OK. Gate will automatically open and close at full torque.
4.Once “OK” is displayed on the screen, press OK.
5.Press + and – at the same time to exit programming.
MAIN MENU
PARAM
LOGIC
RADIO
LANGUAGE
DEFAULT
AUTOSET
INITIAL PROGRAMMING
14
