Page #9 background imageLoading...
Page #9 background image
INSTALLATION MANUAL
51-52
Clock input (N.O.). If the connected contact is open (N.O.), the
leaves close and get ready for normal operation. If the contact
is closed (N.C.), the leaves open and stay open until the contact
reopens. If the opening movement controlled by the TIMER is
prevented by the safety devices, gate opening can be resumed
by activating the START/OPEN control.
52-55
Input for photocelledge contact on closing SAFE CL (N.C.). In
case of activation during closing, the gate is stopped and partly
reopened. If not used, leave the jumper connected.
53 Photocell test input (PHOT-FAULT).
54 Safety edge/opening photocell test input (BAR-FAULT).
56 Closing photocell test input (PHOT CL-FAULT).
JP7 Radio receiver board connector.
JP8 Optional card connector (SCS)
JP9 Trac-light / Preheating SSR5 board connector.
5) CONNECTION WITH EXPANSION BOARDS AND UNIVERSAL HANDHELD
PROGRAMMER (Fig. A)
Refer to specic manual.
6 SAFETY DEVICES
NOTE: ONLY USE RECEIVING SAFETY DEVICES WITH FREE CHANGEO
VER CONTACT.
6.1 TESTED DEVICESFIG. D
6.2 NONTESTED DEVICES FIG. C  D
7 CALLING UP MENUS: FIG. 1
7.1) PARAMETERS MENU PARA
 PARAMETERS TABLE A
7.2) LOGIC MENU LOGIC LOGIC TABLE “B”
7.3) RADIO MENU radio RADIO TABLE C”
- IMPORTANT NOTE: THE FIRST TRANSMITTER MEMORIZED MUST BE
IDENTIFIED BY ATTACHING THE KEY LABEL (MASTER).
In the event of manual programming, the rst transmitter assigns the RE-
CEIVER’S KEY CODE: this code is required to subsequently clone the radio
transmitters.
The Clonix built-in on-board receiver also has a number of important ad-
vanced features:
Cloning of master transmitter (rolling code or xed code).
Cloning to replace transmitters already entered in receiver.
Transmitter database management.
Receiver community management.
To use these advanced features, refer to the universal handheld programmer’s
instructions and to the general receiver programming guide.
7.4 LANGUAGE MENU language
Used to set the programmer’s language on the display.
7.5 DEFAULT MENU default
Restores the controllers DEFAULT factory settings.
8) SCS OPTIONAL MODULES
8.1) SERIAL CONNECTION USING SCS1 BOARD (Fig. A - E)
The RIGEL 5 control panel allows several automation units (SCS1) to be
connected in a centralised way by means of appropriate serial inputs and
outputs. This makes it possible to use one single command to open and close
all the automation units connected.
Following the diagram in Fig. E, proceed to connecting all the RIGEL 5 control
panels, exclusively using a telephone-type line.
Should a telephone cable with more than one pair be needed, it is indispen-
sable to use wires from the same pair.
The length of the telephone cable between one appliance and the next
must not exceed 250 m.
At this point, each of the RIGEL 5 control panels must be appropriately
congured, by setting a MASTER unit rst of all, which will have control over
all the others, to be necessarily set as SLAVE (see logic menu).
Also set the Zone number (see parameter menu) between 0 and 127.
The zone number allows you to create groups of automation units, each
one answering to the Zone Master unit. Each zone can only be assigned
one Master unit, the Master unit in zone 0 also controls the Slave units
in the other zones.
8.2) Interface with WIEGAND systems via SCS-WIE module.
Refer to the SCS-WIE modules instructions.
9) SSR5 TRAFFIC-LIGHT / MOTOR PREHEATING BOARD
When inserted in the appropriate connector, it provides:
- Control of two trac lights with 2 lights each.
- Preheating of motors for cold climate.
Refer to specic manual.
9.1) Trac light layout
Trac light 1 must be positioned on the outside of the gate and trac light
2 on the inside.
WARNINGS - Place signs for speed limitation to “Walking pace.
9.2) Motor preheating layout
The “S” probe must be positioned and xed on the outside to detect exter-
nal temperature. It is to be connected to respective terminals 7-8 on the
preheating board.
WARNINGS - Move the EBP solenoid lock and ashing light to 12-13. (Fig.
A Ref. 2)
WARNINGS - Set ashing light dipswitch = ON
RIGEL 5 - 21
D811472 00100_01
