CONTROL PANEL
1) GENERAL INFORMATION
The THALIA control panel comes with standard factory settings. Any change
must be made using the programmer with built-in display or universal handheld
programmer. The Control unit completely supports the EELINK protocol.
Its main features are:
- Control of 1 or 2 24V BT motors
Note: 2 motors of the same type must be used.
- Electronic torque control with obstacle detection
- Limit switch control inputs based on motor selected
- Separate inputs for safety devices
- Built-in radio receiver rolling code with transmitter cloning.
The board has a terminal strip of the removable kind to make maintenance
or replacement easier. It comes with a series of prewired jumpers to make the
installer’s job on site easier.
The jumpers concern terminals: 70-71, 70-72, 70-74. If the above-mentioned
terminals are being used, remove the relevant jumpers.
TESTING
The THALIA panel controls (checks) the start relays and safety devices (photo-
cells) before performing each opening and closing cycle.
If there is a malfunction, make sure that the connected devices are working
properly and check the wiring.
2) TECHNICAL SPECIFICATIONS
Power supply 220-230V 50/60 Hz*
Low voltage/mains insulation > 2MOhm 500V
Operating temperature range -20 / +55°C
Thermal overload protection Software
Dielectric rigidity mains/LV 3750V~ for 1 minute
Motor output current max. 7.5A+7.5A
Motor relay switching current 10A
Maximum motor power 180W + 180W (24V
)
Accessories power supply
24V~ (demand max. 1A)
24V~safe
AUX 0
NO 24V
powered contact (max.1A)
AUX 3
NO contact (24V~/max.1A)
Fuses see Fig. K
N° of combinations 4 billion
Max.n° of transmitters that can be memorized 63
(*other voltages to order)
Usable transmitter versions:
All ROLLING CODE transmitters compatible with
2.1) VIRGO BAT BATTERY KIT (OPTIONAL)
3) TUBE ARRANGEMENT Fig.A
Arrange the electrical installation as shown in g.A.
Keep the mains voltage connections denitely separate from the very low volt-
age connections (24V).
For this purpose, the operator is provided with appropriate ttings, indicated in Fig.A,
for a spiral exible raceway with an inside diameter of 20:
- P1 input for mains power supply.
- P2/P3 inputs for safety devices and accessories.
For the mains power supply, use the appropriate cable clamp (Fig.A -”S”).
4) TERMINAL BOARD WIRING Fig.K
WARNINGS - When performing wiring and installation, refer to the standards in
force and, whatever the case, apply good practice principles.
Wires carrying dierent voltages must be kept physically separate from each other,
or they must be suitably insulated with at least 1mm of additional insulation.
Wires must be secured with additional fastening near the terminals, using devices
such as cable clamps.
All connecting cables must be kept far enough away from the dissipater.
WARNING! For connection to the mains power supply, use a multicore cable
with a cross-sectional area of at least 3x1.5mm2 of the kind provided for
by the regulations in force. To connect the motors, use a cable with a cross-
sectional area of at least 1.5mm2 of the kind provided for by the regulations
in force. The cable must be type H05RN-F at least.
5) MOTOR CONNECTION AND LIMIT SWITCH ADJUSTMENT (Fig. J)
With the gate completely closed and open, rotate the corresponding cam until
you hear the relevant limit microswitch click and lock in position with the ap-
propriate screws.
Check the limit switches have activated correctly, starting some motorized open-
ing and closing complete cycles.
Terminal Denition Description
Power supply
L LINE
Single-phase power supply
220-230V 50/60 Hz*
N NEUTRAL
JP5
TRANSF PRIM Transformer primary winding connection, 220-230V.
JP7
JP21 TRANSF SEC
Board power supply:
24V~ Transformer secondary winding
24V= Buer battery power supply
Motor
10 MOT1 +
Connection motor 1. Time lag during closing.
Check connections shown in Fig.J
11 MOT1 -
14 MOT2 +
Connection motor 2. Time lag during opening.
Check connections shown in Fig.J
15 MOT2 -
Aux
20
AUX 0 - 24V
POWERED
CONTACT (N.O.)
(MAX. 1A)
AUX 0 congurable output - Default setting FLASHING LIGHT.
2ND RADIO CHANNEL/ SCA GATE OPEN LIGHT/ COURTESY LIGHT command/ ZONE LIGHT command/ STAIR LIGHT/ GATE OPEN
ALARM/ FLASHING LIGHT/ SOLENOID LATCH/ MAGNETIC LOCK/ MAINTENANCE/ FLASHING LIGHT AND MAINTENANCE. Refer to
“AUX output conguration” table.
21
26
AUX 3 - FREE
CONTACT
(N.O.)
(Max. 24V 1A)
AUX 3 congurable output - Default setting 2ND RADIO CHANNEL Output.
2ND RADIO CHANNEL/ SCA GATE OPEN LIGHT/ COURTESY LIGHT command/ ZONE LIGHT command/ STAIR LIGHT/ GATE OPEN
ALARM/ FLASHING LIGHT/ SOLENOID LATCH/ MAGNETIC LOCK.
Refer to “AUX output conguration” table.
27
Limit switch
for
VIRGO SMART
BT A
5 wires
41 + REF SWE Limit switch common
42 SWC 1 Motor 1 closing limit switch SWC1 (N.C.).
43 SWO 1 Motor 1 opening limit switch SWO1 (N.C.).
44 SWC 2 Motor 2 closing limit switch SWC2 (N.C.).
45 SWO 2 Motor 2 opening limit switch SWO2 (N.C.).
Limit switch for
VIRGO SMART
BT A
3 wires
42 SW 1
Limit switch control motor 1.
For actuators with single-wire limit switch control.
43 SW 2
Limit switch control motor 2.
For actuators with single-wire limit switch control.
Accessories
power supply
50 24V-
Accessories power supply output.
51 24V+
52 24 Vsafe+
Tested safety device power supply output (photocell transmitter and safety edge transmitter).
Output active only during operating cycle.
Commands
60 Common IC 1 and IC 2 inputs common
61 IC 1
Congurable command input 1 (N.O.) - Default START E.
START E / START I / OPEN / CLOSE / PED / TIMER / TIMER PED
Refer to the “Command input conguration” table.
62 IC 2
Congurable command input 2 (N.O.) - Default PED.
START E / START I / OPEN / CLOSE / PED / TIMER / TIMER PED
Refer to the “Command input conguration” table.
