First measurement for (K2)
Use a 1.4 mm thick dial.
Install the small bearing only with a 1.4 mm thick dial.
The small engaging bearing will only lock into one position
because of the 4 grooves.
Rotate to check that the bearing is correctly installed with the
grooves in their right position.
Place the slip gauge onto the small bearing.
