Assemble the blast gun.
After you complete the assembly of the SBC.
Then you shall assemble the transparent to lid
(1). Please lock up the movable leaf above the
rear panel (3).
Upon locking up the movable leaf.
Put the transparent top lid under the moveable
leaf to lock up the handle first. Then put item
(22) through the holes on the moveable leaf.
Step 10
Open up the top lid and connect the positioning
chain.
Please connect the two ends of the chain with
the screw and nut as illustrated.
This prevents falling down of the top lid when it
is opened.
