English
3
MAIN PARTS
1 Water tank lid 11 Cup holder (small cups)
2 Water tank 12 Cup holder (mugs)
3 Used capsule drawer 13 Drip tray
4 Power cord 14 Power button
5 Capsule loading tray 15 Chassis plug
6 Cup holder surface 16 Ventilation fan
7 Touch control panel 17 Display
8 Hot water dispensing spout 18 Coffee dispensing spout
9 Moving coffee dispensing spout 19 Cappuccinatore
10 Cappuccinatore cover
