DF MANUAL INTRODUCTION
Manual version 3.0 - North America (15-07-2014) en-5
en
1.2.2 Symbols used on the unit and in the manual
The following symbols indicate possible risks or hazards. The
same symbols will also be found on the unit.
1.2.3 Related documentation
In addition to this manual, the following documentation is also
supplied with the unit:
• wiring diagram for installation and servicing.
1.3 About the unit
1.3.1 Application and operation of the air curtain
The air curtain is designed to separate indoor and outdoor cli-
mates. The unit draws air from the room and discharges it,
either heated or not, across the width of the doorway. The air
curtain removes the undesired effects of an open door by
either reducing the exchange of indoor and outside air, by
heating the entering air, or a combination of the two.
Mounting methods
The free-hanging model is designed for free, visible installation
above the door.
S
YMBOL DESCRIPTION
w You have accessed a section of the unit with components carrying a volt-
age.
Access restricted to qualified maintenance staff only.
Caution is required.
w This surface or component may be hot. Risk of burns on contact.
