Biddle DF Series - Hanging the Unit up

INSTALLATION COMFORT AIR CURTAIN
en-14
en
2.4 Hanging the unit up
2.4.1 Determining the location of the unit
• Make sure that the structure from which the unit is about
to be suspended can bear the weight of the unit. The unit’s
weight is marked on its type plate.
• Note the following dimensions:
- The unit must be at least as wide as the door opening
(dimension b).
- Position the unit as near to the doorway as possible.
- Position the unit as close to the top of the door as pos-
sible.
Warning:
w The minimum installation height (dimension
h) is 1.8 m (6 ft).
Warning:
w The top of the unit may get hot. The unit
should be placed with at least 25 mm(1")
ceiling clearance (dimension x).
- If the unit is mounted against the ceiling:
Make sure that air can enter the unit freely above the
unit.
See also:
1.3.3 "Type plate" on page 8
