INTRODUCTION COMFORT AIR CURTAIN
en-8
en
1.3.3 Type plate
The type plate is located on the top of the unit.
Example of a type plate Designations on the type plate
1.3.4 CE declaration
The unit is compliant with the applicable CE standards. The
complete CE Declaration of Conformity can be found at:
www.biddle.info
1.3.5 Modifications and changes
Without the approval of Biddle, no changes or modifications
may be made to the unit that could adversely affect safety.
1.3.6 Components and accessories
For all models:
• control panel (supplied separately – can be used for multi-
ple units)
• control cable – Type RJ4 (supplied separately)
• optional:
door contact switch (supplied separately)
DESIGNATION MEANING
Type complete type code of the unit
Mweight of unit
P
max
For water-heated models:
max. permissible operating pressure
U power supply voltage
I
max
max. current
P
motor
max. power consumption by fans
P
heating
For electrically heated models:
max. power consumption by heating
element
