REV B 3-12 605228
These anti-scalp wheels are designed to minimize scalping
when mowing on rough, uneven terrain.
After setting the cutting height, adjust the anti-scalp wheels so
they extend below the deck but do not contact the ground.
They should always be at least 1/4” to 3/4” (6.35mm to
19.05mm) below the deck. With the unit sitting on a flat level
surface, the wheel position can be adjusted up or down as
needed from 3/4” to 1-3/4” (19.05mm to 44.45mm) below the
blade surface. Move the wheels up or down, in 1/2” (12.70mm)
increments, using the different axle mount holes in the wheel
mount bracket. Fig. 3-13
When adjusting the rear anti-scalp wheels, the wheel should
be in the same axle mount hole as the front anti-scalp wheels.
Fig. 3-13
Anti-scalp
wheel
Adjusting
holes
