19" LCD MONITOR
REV A
14
5.4 Analog and digital inputs (DVI-D, VGA)
15-pin Sub-D connector
Connect VGA cable with 15-pin Sub-D connector (male) for the analog input
to the 15-pin Sub-D connector (female).
DVI socket
With DVI digital signal.
5.5 Power supply connection
Note
Device fuses can not be exchanged outside of the repair centers.
The display power supply is connected using an appliance plug. Only use the
power cable supplied in the delivery, or a cable with PE conductor and
appliance socket to DIN 49 547, IEC 320.
Caution
A power cable with PE conductor must be used which corresponds to the
safety requirements of the respective country of use.
5.6 Serial interface
Caution
No other units may be connected to the service socket. Connection or
disconnection of a unit may only be carried out by servicing personnel or
those trained by them. A Serial Spot Meter or Universal Serial Luminance
Meter must not be connected in the presence of patients.
The display has a serial RS 232 interface sockets to update the SW.
