19" LCD MONITOR
REV A
24
8.3 Electronics
Multi-standard technology Video modes with resolutions less than 1280 x
1024 can be expanded to the TFT resolution,
and thus utilize the full display area (like
multi-sync CRTs).
In the same way, resolutions higher than 1280
x 1024 can be reduced and then displayed.
(Caution: depending if the timing is frame
buffered or frame sync, image information
might get lost; the gray levels - the color depth
for color images - will also be reduced and
might be visible)
Timing recognition H frequency, V frequency
8.4 Inputs/outputs
8.4.1 Analog signal input
RGB input, H/C Sync
input and V Sync input
Via 15-pin Sub-D connector (female)
Any polarity
DVI-D input
Via DVI-D socket (analog pins are
used)
CVS signal
Video level: 0.5 ... 1.0 Vpp
Sync level: 0.2 ... 0.3 Vpp
8.4.2 Digital signal input
DVI-D input Via DVI socket , single link
DDC Via DVI
