19" LCD MONITOR
REV A
23
8. Technical data
All technical data are valid after a warming-up period of 2 hours.
8.1 Display
Type TFT,color active matrix
Display area 376.32 mm x 301.056 mm
Picture diagonal 19" or 48 cm
Native resolution 1280 x 1024 (full-screen format)
Pixel organization 3 vertical sub pixels
Pixel pitch 0.294 mm x 0.294 mm
Contrast ratio Typically 1000:1
Horizontal
viewing angle
Typically ± 85°
Vertical viewing
angle
Typically ± 80°
Backlight 4pcs* CCFT (cold cathode fluorescent tube)
Brightness Typically 450 cd/m² Factory setting: 300 cd/m²
Lifetime of
backlight
50,000 hours typically for CCFT
(applies to an ambient temperature for the backlight of 25°C )
8.2 Power supply
Input Voltage
100-240V
~, 50 / 60Hz; 0.9A-0.4A
Power
Consumption
Normal
operation
<60W
Power
Supply
Input Connector 3P IEC Type
