Bigtide HL1916V - Timing Input; Controls and connection elements

19" LCD MONITOR
REV A
25
8.4.3 Serial interface
RS232 Via D-sub 9pin
8.4.4 Timing Input
Analog Digital
Horizontal frequency 31kHz -82kHz 31kHz -82kHz
Vertical frequency
50.0Hz - 85.0 Hz
(Non-Interlaced)
50.0Hz - 85.0
Hz
(Non-Interlaced)
Video Signal Analog RGB Digital RGB
Sync. Signal
Separate Sync. (TTL)
Composite Sync.
Sync on green
TMDS
Pixel Clock 25.0MHz -140.0MHz
25.0MHz
-140.0MHz
Input
Signals
Input connector Mini D-sub 15Pin DVI-D
8.5 Controls and connection elements
Left Side Four keys for OSD menu, operation-LED
Rear
• Power switch
•Power supply connection
• DVI socket
• 15-contact 3-row Sub-D socket
• RS 232 sockets Sub-D 9 pin
