BILJAX 45XA
43
SPECIFICATIONS
SERIAL NUMBER__________________
Working Height
51 ft
15.7 m
Maximum Platform Height
45 ft
13.7 m
Maximum Horizontal Outreach
From Centerline
From Outrigger Footpad Edge
27 ft
8.2 m
21 ft
6.4 m
Rated Platform Capacity
Without Platform Rotation
With Platform Rotation
500 lbs
227 kg
440 lbs
200 kg
Maximum Occupants
2
Total Weight
4,300 lbs
1,950 kg
Turntable Rotation
700º Non-Continuous
Leveling Capability
12.5º
Gradeability
48%
Wheel Base
8 ft 8 in
2.7 m
Turning Radius
Inside
Outside
11 ft
3.35 m
16 ft 8 in
5 m
Platform Dimensions
Height
Length
Width – US/CE
3 ft 7 in
1.1 m
2 ft 6 in
0.8 m
5 ft/4 ft
1.5 m/1.2 m
Stowed Dimensions
Height
Length
Width
6 ft 4 in
2.0 m
19 ft 2 in
5.8 m
5 ft 5 in
1.7 m
Outrigger Footprint
Length
Width
Footpad Diameter
12 ft 2 in
3.7 m
11 ft 4 in
3.4 m
12.5 in
0.3 m
Brake
Spring Applied
Speed
Gas Power
DC Power
3.75 mph
6 km/h
2 mph
3.2 km/h
Tire Size
26 x 12 bar lug tires
Tire Pressure
20 PSI
140 kPa
Control System
24V DC
Battery
4 x 6V 245 amp-hr
Battery Charger
110/120 Volt
Gas Engine
Kawasaki 21 HP
Hydraulic Pressure
3,000 psi
20,684 kPa
Reservoir Capacity
4.3 Gallons
16.3 L
Hydraulic System Capacity
6.3 Gallons
23.9 L
Hydraulic Oil (Standard)
Dexron III/Mercon ATF
Platform Rotation/Type (Optional)
90º/Manual
Maximum Decibel Level
DC Mode – Ground
DC Mode – Platform
Gas Mode – Ground
Gas Mode - Platform
60 dB
55 dB
70 dB
65 dB
Localized Pressure per Outrigger
25 PSI
1.8 kg/cm
2
176.5 kPa
Operation Temperature Range
-20º to 110º Fahrenheit
-29º to 43º Celsius
Max. Pressure Per Tire – Floor
Loading
35 PSI
2.5 bar
