VoIP/(802.11g) ADSL2+ (VPN) Firewall Router
Chapter 4: Configuration
98
Configuring the L2TP VPN in the Office
Item Function Description
1
Connection Name VPN_L2TP Given name of L2TP connection
Dial out Check Dial out
2
Server IP Address (or
Hostname)
69.121.1.33 An Dialed server IP
Username username
3
Password 123456
A given username & password
4
Auth.Type Chap(Auto) Keep as default value in most of the cases.
5
Idle Timeout 0
The connection will be disconnected when there
Is no traffic in a predefined period of time. Idle
time 0 means the connection is always on.
IPSec Enable for enhancing your L2TP VPN security.
Authentication MD5
Encryption 3DES
Perfect Forward
Secrecy
None
6
Pre-shared Key 12345678
Both sites should use the same value.
To Next Page
