Billyoh NS-0060 - Assembly - Roof Sheet Installation; Roof Sheet Positioning and Fixing Guide

For Queries and Help please call Product Support: 01909 768840
N30 x 5
x 1
1172mm or
879mm
Repeat for all
roof sheets
Roof Fixing Stage
1172mm or
879mm
(FR-0879-SQ /
FR-1172-SQ)
Side View
Correct Position
Side View
Incorrect Position
Roof Sheet Position
Line up the Roof Sheet with
the framing not the cladding
2
2
1
S50 x 12
(FR-1631
-BV2)
1631mm
Roof Sheet requires
Roof Support only
7KH5RRI6KHHWVKRXOGȴWKDOI
ZD\DFURVVWKH5RRI7UXVV
N30 x 15
Position the
Roof Sheet
square with
ȴUVWVKHHW
and push up
to the centre
N30 x 15
Position the Roof Sheet
square with the framing
31
34
35 36
32 33
