170 MAINTENANCE AND ADJUSTMENT
Setting Tables
Front Fork Spring Preload Setting
Softest setting limit Standard Hardest setting limit
Adjuster Position 0* 8 turns in** 18 turns in**
Spring Action Weak ←→ Strong
Setting Soft ←→ Hard
Load Light ←→ Heavy
Road Good ←→ Bad
Speed Low ←→ High
*: This position is the fully open position (turned fully counterclockwise).
**: In from the fully open position (turned fully counterclockwise). This adjustment
range may not exactly match the number shown in the table due to small tolerance
of production.
