APPENDIX 201
Location of DFI System Diagnostic Connector
The DFI system diagnostic connector is located in front on the right side.
A
A. Bolts
Unscrew bolts with key .
A
A. DFI System Diagnostic Connector
Vehicle Data Recording
This vehicle’s ECU stores certain data to assist in problem diagnosis, and for
other purposes such as periodic technical inspection, regulatory compliance, and
research and development.
