MAINTENANCE AND ADJUSTMENT 173
Rear Shock Absorber Damping Force Setting
Softest setting limit Standard Hardest setting limit
Adjuster
Position
Rebound 44 clicks out**
22 clicks out** 0*
Comp 54 clicks out**
Damping Force Weak Strong
Setting Soft Hard
Load Light ←→ Heavy
Road Good ←→ Bad
Speed Low ←→ High
*: This position is the fully seated position (turned fully clockwise).
**: Out from the fully seated position (turned fully clockwise). This adjustment range
may not exactly match the number shown in the table due to small tolerance of
production.
