pg.13
6.3. EDID Configuration
6.3.1. EDID Mode Settings
6.3.2. Learning EDIDs
In most cases, EDIDs will not require learning from the display. Only perform learning if
none of the EDIDS available using the Mode Dial does not provide the desired outcome.
1. Set the EDID Mode dial to “7”.
2. Connect the HDMI display to “HDMI IN” on the Transmitter with a HDMI cable.
3. Set “MODE” on the transmitting unit to “7”.
4. Power on the Transmitter by connecting the 5V Power Supply.
5. The LED on the RJ45 of the transmitter will ash On and O once to learn the EDID.
Keep the mode dial on “7” at all times to use the learned EDID.
6. Unplug the HDMI cable from the display and follow the installation instructions in
section 6.1 B-320-1CAT-HDIR Transmitter Installation.
EDID Setting Supported Resolutions Color Depth Audio Channels
0 1080p @60Hz 24-Bit 7.1 ch
1 1080p @60Hz 24-Bit 2 ch
2 1080p @60Hz 36-Bit 7.1 ch
3 1080p @60Hz 24-Bit 3D 7.1 ch
4 1080p @30Hz
1080i @60Hz,
720p @60Hz
24-Bit 7.1 ch
5 1080p @30Hz
1080i @60Hz
720p @60Hz
24-Bit 2 ch
6 1080p @60Hz 24-Bit 3D 2 ch
7 Learning Mode
