Page #14 background imageLoading...
Page #14 background image
B-320-1CAT-HDIR Installation and Users Manual
pg.14
www.snapav.com Support: 866.838.5052
6.4. Distance Calibration
CAUTION: Inappropriate signal level setting may cause an
overpowering issue that may shorten the product life. Follow
the steps below to adjust the distance setting in order to
avoid overdriving.
1. Set the distance control to 7 (Weakest).
2. Select a source that is outputting the highest-quality video that will be
transmitted to the receiver.
A. If you see a ickering or blinking images on the display:
A-1. Adjust the signal level from 7 to 0 one step at a time, and stop turning
the rotary switch when the audion/video is playing normally.
