Auto-Power-Off (APO)
This feature saves battery life by automatically turning
the handset off if you have not pressed any button for a
set time. You can set the timeout to 1, 2 or 3 hours; or
set it to 0 (zero) to turn APO off.
1 Press the MENU button NINE times
flashes on the display and the current
setting (0
hr to 3hr) is shown.
2 Press the ▲ or ▼ button to change the
setting
3 Press the PTT button to return to normal
operation
is shown on the display as long as APO is
turned on. It disappears if you set APO
to 0
hr.
Using the hands-free kit
To connect the hands-free kit to your MR700 handset,
plug it into the socket at the side of the handset.
With the hands-free kit connected, you may want to
transmit using the VOX function (see page 8). If you
find that this doesn’t work very well, you can turn the
VOX sensitivity to 0 (off) and press the PTT button to
transmit, as normal.
!
If you use any hands-free accessories other than the
kit supplied, make sure they are approved, and from
a reputable supplier. Other accessories may cause
damage not covered by the guarantee.
16
Technical details
Operating frequency 446.00625 to 446.09375 MHz
(eight channels)
Channel spacing 12.5 kHz
Power source 4 × AAA rechargeable NiCad battery.
4.8 V, 300 mAh
Channel Frequency
(MHz)
Channel Frequency
(MHz)
1 446.00625 5 446.05625
2 446.01875 6 446.06875
3 446.03125 7 446.08125
4 446.04375 8 446.09375
Declaration of conformity
The Binatone MR700 conforms to the following
standards:
■
EN 301489 (RF testing)
■
EN 300296 (EMC testing)
■
EN 60065 (safety testing)
Cleaning and care
To clean your MR700, use a soft cloth dampened with
water. Do not use cleaners or solvents, which may
cause permanent damage not covered by the guarantee.
Binatone Help Line: 01325 304 473 17
