Binder FED 240 - Word Message Panel Structure; Localization; Position of Safety Labels on the Chamber

FED (E2) 02/2015 page 6/60
Prohibition signs
Do NOT touch
Do NOT spray with
water
Information to be observed in order to ensure optimum function of the product.
1.2.4 Word message panel structure
Type / cause of hazard.
Possible consequences.
∅ Instruction how to avoid the hazard: prohibition
 Instruction how to avoid the hazard: mandatory action
Observe all other notes and information not necessarily emphasized in the same way, in order to avoid
disruptions that could result in direct or indirect injury or property damage.
1.3 Localization / position of safety labels on the chamber
The following labels are located on the chamber:
Pictograms (Warning signs)
Service label
Hot surface
• Outer chamber door
• On chamber rear next to the exhaust
duct
Read operating manual
• UL chambers: on outer chamber door
Figure 1: Position of labels on the chamber front
