Service  documentation series KB/KBF
BB / JTU 25.06.2000
Trouble Shooting KB / Cooling System
Assumption: No Cooling
Do Controller (N1) emits a Signal to the Solid State Relay (K3) ?
Æ
ÆÆ
Æ
YES Check the Solid State Relay (K3)
Æ
ÆÆ
Æ
NO Change the Controller (N1)
Does the Solid State Relay (K3)
Æ
ÆÆ
Æ
YES Check the voltage at the Terminal-Block
Æ
ÆÆ
Æ
NO Solid State Relay (K3) defect
Is there a current at the Compressor ?
Æ
ÆÆ
Æ
YES Compressor is defect, change the Compressor
Æ
ÆÆ
Æ
NO Check the cabling
Trouble Shooting KBF / Cooling System
Assumption: No Cooling
Does the Controller (N1) emits a Signal?
Æ
ÆÆ
Æ
YES Check the Compressor and Solenoid Valve
Æ
ÆÆ
Æ
NO Controller (N1) is defect
Does the Compressor work?
Æ
ÆÆ
Æ
YES Possible that there is no refrigerant inside the chamber
Æ
ÆÆ
Æ
NO Check the voltage at the Terminal-Block
Is there a voltage at the Compressor?
Æ
ÆÆ
Æ
YES Compressor is defect
Æ
ÆÆ
Æ
NO Check the cabling
