PARTS LIST / 81883X FLUID SECTION
L 862040 Diaphragm Repair Kits include: Item # 2 7 8 19 20 33 Grease Packet Operator's Manual
(standard for models 818833, 818836) Qty 1 2 2 4 2 4 1 1
~ 862041 Diaphragm Repair Kits include: Item # 2 3 7 19 20 33 64 Grease Packet Operator's Manual
(standard for models 818831) Qty 1 2 2 4 2 4 2 1 1
s 862042 Diaphragm Repair Kits include: Item # 2 7 19 20 33 Grease Packet Operator's Manual
(standard for models 818832, 818835) Qty 1 2 4 2 4 1 1
V 862045 Ball and Seat Repair Kits include: Item # 19 20 21 22 Grease Packet Operator's Manual
(stainless steel ball and seat) Qty 4 2 4 4 1 1
(standard for models 818831, 818833 and 818836, optional for all others)
z 862046 Ball and Seat Repair Kits include: Item # 19 20 21 22 Grease Packet Operator's Manual
(PTFE ball & stainless steel seat) Qty 4 2 4 4 1 1
(optional for all models)
Y 862047 Ball and Seat Repair Kits include: Item # 19 20 21 22 Grease Packet Operator's Manual
(optional Santoprene ball & stainless steel seat) Qty 4 2 4 4 1 1
(standard for models 818832 and 818835, optional for all others)
WETTED COMMON PARTS / 818831, 818832, 818833, 818835, 818836
818831 818832 818833 818835 818836
Item Description (size in inches) Qty Part No. [Mtl] Part No. [Mtl] Part No. [Mtl] Part No. [Mtl] Part No. [Mtl]
1 Connecting Rod (1) 873035 [SS] 873035 [SS] 873035 [SS] 873035 [SS] 873035 [SS]
s L ~ 2 O" Ring (3/32" x 5/8" o.d.) (1) [B] [B] [B] [B] [B]
~ 3 O" Ring (1/16" x 9/16" o.d.) (2) [T] ----- --- ----- --- ----- --- ----- ---
5 Diaphragm Washer (2) 873403 [GFN] 873403 [GFN] 873403 [GFN] 873403 [GFN] 873403 [GFN]
6 Diaphragm Nut (5/16" Ć 18) (2) 873289 [D] 873290 [P] 873290 [P] 873290 [P] 873289 [D]
s L ~ 7 Diaphragm (2) [T] [SP] [T] [SP] [T]
L 8 Diaphragm (models 818833, 818836) (2) ---- --- ----- --- [SP] ----- --- [SP]
15 Fluid Cap (Includes items 26 & 124) (2) 873291 [GA] 873292 [P] 873292 [P] 873292 [P] 873291 [GA]
YszVL~ 19 O" Ring (3/32" x 1Ć5/16" o.d.) (4) [T] [E] [T] [E] [T]
YszVL~ 20 O" Ring (3/32" x 1Ć1/8" o.d.) (2) [T] [E] [T] [E] [T]
Y z V 21 Seat (4) [SS] [SS] [SS] [SS] [SS]
V 22 Ball (3/4" diameter) (4) [SS] [SS] [SS] [SS] [SS]
z Ball (3/4" diameter) (4) [T] [T] [T] [T] [T]
Y Ball (3/4" diameter) (4) [SP] [SP] [SP] [SP] [SP]
26 Bolt (5/16" Ć 18 x 1Ć1/2") (8) [SS] [SS] [SS] [SS] [SS]
29 Nut (5/16" Ć 18) (2) [SS] ----- --- ----- --- ----- --- [SS]
41 Ball Cage (4) 873295 [D] 873296 [P] 873296 [P] 873296 [P] 873295 [D]
43 Ground Strap (1) [SS] ----- --- ----- --- ----- --- [SS]
57 Ground Kit Assembly (not shown) (1) 873067 ----- --- ----- --- ----- --- 873067
60 Manifold, Inlet (Bottom) (1) 873412 [GA] 873234 [P] 873234 [P] 873234 [P] 873412 [GA]
61 Manifold, Outlet (Top) (1) 873138 [GA] 873235 [P] 873235 [P] 873235 [P] 873138 [GA]
62 Flange Nut (5/16" Ć 18) (24) ----- --- [SS] [SS] [SS] ----- ---
Flange Nut (5/16" Ć 18) (22) [SS] ----- --- ----- --- ----- --- [SS]
63 Pipe Plug (1/2 Ć 14 N.P.T. x 9/16") (6) 873429 [D] 873428 [P] 873428 [P] 873428 [P] 873429 [D]
~ 64 O" Ring (.210" x 4.576" o.d.) (2) [U] ----- --- ----- --- ----- --- ----- ---
MATERIAL CODE
[B] = Nitrile [P] = Polypropylene
[D] = Acetal [SP] = Santoprene
[E] = E.P.R. [SS] = Stainless Steel
[GA] = Groundable Acetal [T] = PTFE
[GFN] = Glass Filled Nylon [U] = Polyurethane
