5
NOZZLE AND NEEDLE SELECTION CHART
FOR MODEL 95G GRAVITY FEED SPRAY GUNS
Type of Fluids Fluid▲ Air Fluid Max. Pattern CFM Fluid Flow*
Nozzle Nozzle Needle at 8"
20 30 40 20 30 40
Distance
Low to Medium
Viscosity Fluids
(14-20 second-No. 2 Zahn)
Dyes, Stains, Lacquers, 65SS 66SD 865 11" @ 40 PSI 7.5 10.5 13.0 168 209 226
Primers, Waterborne •66SS 66SD 865 15" @ 40 PSI 7.5 10.0 12.0 244 290 350
Coats, Base Coat 66SS 66SK 865 15.5" @ 40 PSI 9.0 11.0 13.5 235 293 367
Metallics L6SS 66SD 865 15" @ 40 PSI 7.5 10.5 13.0
VARIES
L6SS 66SK 865 15.5" @ 40 PSI 9.0 11.0 13.5
WITH
VISCOSITIES
Medium to High
Viscosity Fluids
(19-30 second-No. 2 Zahn/
Over 28 sec.-No. 4 Ford)
Urethanes, Fillers, 65SS 66SD 865 11.5" @ 40 PSI 7.5 10.5 13.0 176 223 263
Epoxies, Varnishes, •66SS 66SD 865 12" @ 40 PSI 7.5 10.0 12.0 205 244 275
Lubricants, Shellacs, 66SS 66SK 865 15" @ 40 PSI 9.0 11.0 13.5 230 302 369
Fillers Waterborne, 67SS 67SK 867 18" @ 40 PSI 9.0 11.5 14.0 348 453 504
Top Coats L6SS 66SD 865 12" @ 40 PSI 7.5 10.5 13.0
VARIES WITH
L6SS 66SK 865 15" @ 40 PSI 9.0 11.0 13.5 VISCOSITY
Vitreous Enamels
(20-30 second-No. 2 Zahn) 67VT
67SK 867VT VARIES WITH
Ceramics, Glazes 68VT
68SA 868VT
FLUID VISCOSITIES
▲
Fluid Nozzle Reference Chart
Nozzle No. 65SS 66SS 67SS 68SS
Orifice Size .059 .070 .086 .110
Tungsten Carbide Fluid Nozzle & Fluid Needle Tip
L-Series Fluid Nozzles tend to minimize “smoking effect” at the
air cap allowing for less fluid build-up at the air nozzle horns.
Typically, they require slightly higher air pressures to achieve
the same fluid delivery as standard No. 60 Series nozzles.
*Fluid flow in cc/minute. Divide above fluid flow by
29.6 to convert to fluid ounces (U.S.)
NOTE
Pressure feed type air nozzles are not recommended to be
used with Model 95G Gravity Feed Spray Gun.
STANDARD SET-UP 66SS X 66SD• – ALL OTHERS ARE OPTIONAL
