BIO-MED DEVICES Crossvent-2i+ - Technical Specifications

III. SPECIFICATIONS, CONNECTIONS AND USER INTERFACE- CONT.
11
B- SPECIFICATIONS
Parameter
Range
Resolution of Display
Accuracy
CMV Rate
1- 150 bpm
1 bpm
±10%
SIMV Rate
0.6- 50 bpm
0.1 bpm below 1, 1 bpm above 1
±10%
CPAP Rate
5- 150 bpm
1 bpm
±10%
Tidal Volume
5- 750 ml
1 ml below 200; 10 ml above 200
±10%
Inspiratory Time
0.1- 3.0
.05 below 1.00, 0.1 above 1.00
±10%
Flow Rate
1- 15 lpm
0.1 lpm below 10; 1 lpm above 10
±10%
Peak Pressure (PIP)
0- 80 cmH
2
O
1 cmH
2
O
±3% FS
PEEP Pressure
0- 20 cmH
2
O
1 cmH
2
O (above baseline)
±3
Flow Trigger
1- 20 (scale)
1 unit
N/A
Pressure Support
1- 50 cmH
2
O
1 cmH
2
O (above baseline)
±3
O
2
Sensor
0- 100 %
1%
±3% FS
EXHTV
0- 1300 ml
0.1 ml below 50; 1 ml from 50-200, 10 ml thereafter
±15%
1
EXHMV
0- 45 L
0.1 L below 10, 1 L thereafter
±15%
1
1. Readings below 10 ml may be considered relative rather than absolute values.
2. NOTE: All values are expressed under ATPD conditions (ambient temperature & pressure dry)
C- ADDITIONAL SPECIFICATIONS
Base Flow
2.5 lpm
Continuous Flow
1 – 15 lpm
Maximum Safety Pressure:
96 cmH
2
O
Pneumatic Power Source
17 – 55 psi (117 kPa – 380 kPa)
Audible Alarm Characteristics
90 dB at 10cm (25°C)
Electrical Power Source
See Appendix E
Output:
16.0 VDC, 3 A
Output Protection:
Short Circuit and Overload
Isolation:
Meets IEC601.1, classification BF, UL 544 Patient Care, CSA 125 Risk Class
2G
Maximum Ripple:
<100 mVp-p
Safety:
Approved to UL 544/2601.1, CLU (CSA) 22.1 #125/601.1, TUV
EN60601.1 & CE LVD
EMC:
Designed to Level B Requirements of FCC part 15, CISPR11 (EN55011).
Less than 1 Volt Output Deviation for IEC801-2, 3, 4, 5, Immunity Tests.
Overall Dimensions
Height:
7.5" (191 mm)
Width:
8.4" (213 mm)
Depth:
4.4" (112 mm)
Weight:
7.65 lbs. (3.5 kg)
Operating Temperature:
32 to 104 degrees F. (0 to 40 degrees C)
1
