BIO RAD PowerPac - User Manual

Other manuals for BIO RAD PowerPac

User Guide20 pages

Questions and Answers

S
samuel53Aug 16, 2025
What causes E01 NO LOAD DETECTED error on BIO RAD PowerPac?
- M
  Melissa NicholsonAug 16, 2025
  If the BIO RAD Power Supply displays the error 'E01 NO LOAD DETECTED CELL & CABLES', it means no load is detected, possibly because the electrophoresis cell is not connected or the current load is less than 0.01 A. Verify all electrical connections, ensure buffer levels are appropriate, and confirm that the electrophoresis application's power requirements match the PowerPac HC output range.
L
Laura AllenAug 19, 2025
What to do if my BIO RAD Power Supply shows error E02 (Short Circuit)?
- J
  jandrewsAug 19, 2025
  If the BIO RAD Power Supply displays the error 'E02 SHORT CIRCUIT CELL & CABLES', it indicates a short circuit, potentially due to accidental shorting of output leads or incorrect connections causing an overcurrent (greater than 3.0 A). Ensure all electrical connections are making good contact, cables and wire electrodes are in good condition, and verify buffer levels are appropriate.
B
blunaAug 22, 2025
How to fix E17 SYSTEM OVERHEATING error on BIO RAD PowerPac?
- A
  angelamurrayAug 22, 2025
  If the BIO RAD Power Supply displays the error 'E17 SYSTEM OVERHEATING', this indicates that the fan vents are blocked, or the ambient temperature is too high. Ensure there is at least 6 cm of clear space around the fan vents to improve airflow. Also, make sure you operate the unit within the recommended temperature range (0 to 40°C). Press any key to go to the home screen to restart.
K
Kevin RiggsAug 26, 2025
Why does my BIO RAD PowerPac Power Supply show error E11 GROUND LEAK DETECTED?
- K
  Kimberly DuffyAug 26, 2025
  If the BIO RAD Power Supply displays the error 'E11 GROUND LEAK DETECTED CELL & CHILLER', it indicates an insulation failure in the electrical connections outside the power supply, creating a current flow that may be unsafe. Check electrical connections and the cell/chiller system for leaks. Ensure the electrophoresis cell rests on an insulated, dry surface.
B
Brooke HarperAug 28, 2025
How do I troubleshoot E09 RESISTANCE CHANGE error on BIO RAD PowerPac Power Supply?
- C
  chelseamcconnellAug 28, 2025
  If the BIO RAD Power Supply displays the error 'E09 RESISTANCE CHANGE DETECTED CELL & CABLES', it means the device has detected a change in load resistance, which might indicate failure of the cell's power leads or a loose output connection. Check and correct any potential resistance problem, verify all electrical connections, and ensure buffer levels are appropriate.
J
John FitzpatrickAug 31, 2025
Why is the fan failing on my BIO RAD PowerPac (E16 error)?
- C
  Christine JohnstonAug 31, 2025
  If the BIO RAD Power Supply displays the error 'E16 FAN FAILURE', it means the fan is not working due to either an electrical failure or a physical obstruction. Inspect the fan grid to check if the fan blade is rotating when the power supply is turned "ON", and ensure no foreign material has penetrated the fan vent. If the problem persists, contact Bio-Rad Technical Resources.
M
Morgan BrownSep 3, 2025
What does E04 REGULATING BELOW 5V mean on BIO RAD Power Supply?
- C
  Christopher SkinnerSep 3, 2025
  If the BIO RAD Power Supply displays the error 'E04 REGULATING BELOW 5V', it indicates a regulation error where the current drawn by the electrophoresis system exceeds the set current limit of the unit, at less than 5 V. Ensure the electrophoresis application settings and power requirements match the PowerPac HC output range.
A
Andrew TranSep 6, 2025
How to troubleshoot a BIO RAD PowerPac Power Supply with no display, lights, or fan?
- J
  Julie ColemanSep 6, 2025
  If your BIO RAD Power Supply shows no display, lights, or fan activity, it could be due to: 1. No AC power: Check if the PowerPac HC is unplugged, if there's a problem with the AC power source, or if the power switch is in the off position "O". 2. Blown fuse: Replace the fuse, referring to Section 4.3 for details.
C
Christopher RichardsonSep 9, 2025
Why does my BIO RAD PowerPac Power Supply keep blowing fuses?
- P
  Pamela SmithSep 9, 2025
  If the BIO RAD Power Supply repeatedly blows fuses, this indicates a hardware failure. Contact Bio-Rad Technical Resources for assistance.
S
Samantha FarmerSep 12, 2025
What to do if leads don't fit BIO RAD Power Supply output jacks?
- G
  Guy GarciaSep 12, 2025
  If the leads from your cell are not long enough to fit the output jacks on the BIO RAD Power Supply, it's because the output terminals for the PowerPac HC are recessed 16 mm to meet safety regulations, and some leads are not long enough to make an electrical connection. Use the PowerPac Adaptor (Catalog number 165-5061), which accommodates most standard 4 mm banana plugs, to make a secure electrical connection. Note that using the PowerPac Adaptor voids EN61010 safety provisions.

Summary

Safety

Caution;Warning

Guidelines for safe operation and potential hazards associated with high output voltages.

Important Safety Notes

Instrument intended for laboratory use, conformity to standards, and modification warnings.

Section 2 Control Features

Section 3 Setup and Operation

Setup and Programming a Run

Guides the user through setting up, programming, and running the power supply.

Editing Run Parameters During a Run

Describes how to pause, edit parameters, and resume a run.

Changing System Defaults using the Setup Menu

Section 4 Maintenance and Troubleshooting

Basic Troubleshooting

User Serviceable Error Messages

Details user-fixable error codes, their causes, and solutions.

Bio-Rad Serviceable Error Messages

Replacing a Fuse

BIO RAD PowerPac Specifications

General

Output Power	300 W
Power Output	300 W
Current Resolution	0.01 A
Frequency	50/60 Hz
Output Voltage	10 to 300 V
Output Voltage Range	10-300 V
Input Voltage	100–240 VAC
