Setting Up the Washer | 33
Attaching the Mist Shield
1. Align the mist shield with the washer so it rests on top of the two posts
(shown in
Figure 16 below) and the two thumbscrew holes in the shield
are lined up with the two holes in the front base of the washer.
2. Insert the two thumbscrews and finger-tighten only.
Thumbscrews
(
2
)
Mist shield
Posts (2)
Figure 16: Attaching the Mist Shield
ELx405 Operator's Guide
