42 | Chapter 3: Operation
ELx405 Front Panel
The front panel on the ELx405 Microplate Washer features a 25-key keypad and a
2-line x 24-character LCD display as shown below.
Figure 17: ELx405 Front Panel With LCD and Keypad
Alphanumeric
keys
Special function keys
Menu functions
(second line of
LCD display)
SoftKeys (4)
LCD display
BIO-TEK ELx405
RUN DEFINE MAINT UTIL
