Page 9
a-5. Parts list
You will find the various parts of the structure supporting the modules
Rope clamp Clamping bolt Ring bolt Thimble
Short screw
(20mm)
Short screw
(30mm)
Nut HU M8 Flat washer L d=8 Tensioner Shackle
Large U profile Small U Profile I-module fixation T-module fixation
Flat washer M
d=8
P1 type formed
section
P1 type formed
section
P1 type formed
section
P1 type formed
section
P1 type formed
section
a-6. Required tools
The tools required to assemble the module support structure are indicated below
Spirit level Flat wrench (Size 13,
Size 10)
Cutting pliers Folding meter rule Allen wrench (Size 6)
