3. Mounting of photovoltaic panels
Before starting mounting, the concrete foundation should have been done first.
a-1.
Description of the symbols used
Safety tips:
This symbol indicates a warning, which, if ignored, could result in risks to people or equipment. Read these passages
carefully.
Example:
Risk of injuries
• Risk of serious injury to the hands
•
Wear protective gloves!
Information
This symbol indicates information on the most appropriate procedure.
Example:
Use a screwdriver to tighten the screws
a-2.
Use a screwdriver to tighten the screws
When assembling the aluminium structure and the module, be sure to follow these safety tips:
Risks of cuts
• Cuts to the hands due to incorrectly deburred parts.
• Wear safety gloves!
Risks of burns
• Risk of burns from parts exposed to high heat.
•
Check the temperature of parts and wear gloves!
Risks of explosions
• Risk of explosion due to improper use of batteries
• Do not smoke or bring a naked flame near the batteries!
Risks of chemical burns
• The acid in the batteries can cause chemical burns.
•
Wear an apron and ant-acid gloves!
a-3.
Table for adjusting the solar panel tilt angle
LATITUDE TILT ANGLE
Latitude < 20° 15°
20° < latitude < 35° Latitude + 10°
Latitude > 35° Latitude + 15°
The minimum tilt angle value of 15° provides for "self-cleaning" of the photovoltaic panel and limits the risk of residual
moisture.
a-4.
Dimensions table
Foundation Fixing points Profiles length
F1 : 1844 mm A : 80 mm Profile P1 (2 parts) : 2340 mm
F2 : 1245 mm B : 380 mm Profile P2 (2 parts) : 802 mm
F3 : 263 mm C : 1300 mm Profile P3 (2 parts) : 300 mm
F4 : 720 mm D : 80 mm Profile P4 (2 parts) : 1013 mm
F5 : 525 mm E : 160 mm Profile P5 (1 part) : 640 mm
F : 120 mm
