Figure 10-6.
CONTENTS
— 10-7 — GAIT TRAINER 2 UTILITIES
Strain Gauge Board LED Codes
D5 Should always be flashing. This means
the Microprocessor on the board is
working.
D4 Indicates no weight is on the Treadmill
when this LED is on.
D3 LED on = auto calibrate is in progress.
D2 LED on = Underweight.
D1 LED on = Overweight.
