NOTE: This MEDICAL ELECTRICAL EQUIPMENT needs special precautions regarding EMC and
n
eeds to be installed and put into service according to the EMC information provided in the
ACCOMPANYING DOCUMENTS.
N
OTE: Portable and mobile RF communications equipment can affect MEDICAL
ELECTRICAL EQUIPMENT.
NOTE: Contact Biodex Medical Systems for additional EMC information.
ELECTROMAGNETIC COMPATIBILITY FOR GAIT TRAINER 2
Standard Test Method Range Limits Result
IEC 61000-3-2 Harmonics 100 Hz to 2KHz Class A THD = 57.54%
IEC 61000-3-3 Flicker observation time (TP) 10 min - -
max voltage change (dmax) 4% .45%
max Rel steady state voltage 3% .14%
change (dc) duration of d(t)>3%(t) .2 sec 0.00 sec
short term flicker Sev (PST) 1.00 .24
long term flicker Sev (PLT) .65 .23
IEC 61000-4-2 Electrostatic
Discharge Contact: 4 & 6Kv pos/neg 1pps no degradation complied
for 10 sec of performance
Air: 2, 4, & 8Kv pos/neg 1pps
for 10 sec
IEC 61000-4-3 Radiated
Immunity 80 MHz to 2500 MHz / 3v/m Horiz no degradation complied
& Vertical @ 1M of performance
IEC 61000-4-4 Electrical Fast PWR Input leads .5, 1, & 2 no degradation complied
Transient/Burst, Kv / pos & neg / 5KHz of performance
Power Leads Rep Rate
IEC 61000-4-6 Conducted 150 KHz to 80 MHz /3Vrms no degradation complied
Immunity, of performance
Power Leads
IEC 61000-4-8 Magnetic 3A/M RMS @ 50/60 Hz no degradation complied
Immunity of performance
IEC 61000-4-11 Voltage Dips
and Interrupts Int Pause % no degradation complied
Duration between
r
eduction of performance
Int 20msec pause 10 sec >95% no degradation complied
of performance
Int 100msec
pause 10 sec
60% no degradation
complied
of performance
Int 500msec pause 10 sec 30% no degradation complied
of performance
Int 5000msec pause 10 sec >95% no degradation complied
of performance
CISPR 11 Conducted 150 KHz - 500 KHz /5 MHz - 30 MHz, 79/73 dbuV QP complied
Emission Class A, Group 1 66/60 dbuV AV
CISPR 11 Radiated 30 MHz – 230 MHz /230MHz - 1GHz, 40/47 dbuVm complied
Emissions Class A, Group 1 @ 10 m
IEC 61000-4-5
Sur
ge
1 Kv, differential, 2 Kv Commons, no degradation complied
Immunity, 1ppm 5 Pos, of performance
Power Leads 5 Neg for total of 10
14. ELECTROMAGNETIC COMPATABILITY
— 14-1 — ELECTROMAGNETIC COMPATIBILITY
