2. Identifying Parts & Adjustment Mechanisms
7
1
11
6
5
8
2
3
9
12
10
4
Figure 1. Side View of BioStep 2
The BioStep 2 includes the following parts and adjustment mechanisms:
1. Display Panel
2. Seat Front-to-Back Release Handle (yellow)
3. Indexed Track
4. Seat Rotation Handle (blue)
5. Arm Cranks
6. Lock Knobs (for arm adjustment)
7. Pivoting Handgrips
8. Support Handgrips with Contact Heart Rate Monitoring
9. Footplates
10. Leveling Glides (2, one on each side and one in front)
11. Grab Handle
12. AC Adapter Battery Recharge Jack
Figure 2. Rear View of BioStep 2
— 5 — IDENTIFYING PARTS
