Easy-size Instructions
1. Place feet on the Footplates.
2. Adjust the seat distance. Lift the yellow handle and slide the seat forward along the
track. The seat is positioned correctly when the user's knees are flexed slightly.
NOTE: The knees should not be locked.
3. Extend the arms as needed. Turn the knobs 1/4 turn to the left to loosen, slide the
arm extensions out, and turn the knobs back to the right to tighten.
Easy-off Instructions
1. Retract the arms. Turn the knobs 1/4 turn to the left to loosen, slide the arm
extensions in, and turn the knobs back to the right to tighten.
2. Adjust the seat. Lift the yellow handle and slide the seat backward along the track.
3. Rotate the seat 90°. Lift the blue handle and move the seat away from the Display
Panel until the seat snaps into place.
4. If necessary, have the user hold the Grab Handle for stability before standing up.
MAKING ADJUSTMENTS — 8 —
