8 | 第二章: 硬體安裝
步驟4: 固定CPU,將拉桿閉合。
»
請於拔除CPU插槽之前關閉電源
2�2 散热片
<類型A>
步驟1: 將散熱片和風扇零件放置在支架上。散熱片夾對準插座並固定凸耳,再將彈簧夾
扣到固定凸耳上。
步驟2: 將另一邊的固定夾向下壓,扣住支架上的塑膠凸耳。然後固定,使風扇和散熱片
扣住支架底座。

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Biostar A320MH 2.0 and is the answer not in the manual?

Biostar A320MH 2.0 Specifications

General IconGeneral
Form FactorMicro ATX
ChipsetAMD A320
CPU SocketAM4
Memory TypeDDR4
Memory Slots2
Maximum Memory32GB
PCIe Slots1 x PCIe 3.0 x16, 2 x PCIe 2.0 x1
LANRealtek RTL8111H Gigabit LAN
SATA Ports4
M.2 Slots1 x M.2
USB Ports6 x USB 2.0
Video OutputsHDMI, VGA
AudioRealtek ALC887 8-Channel HD Audio
