第二章: 硬體安裝 | 9
A320MH 2�0
<類型B>
步驟1: 取下主板上的散熱片和風扇零件支架,並保留散熱風扇的鐵背板於主板下方。
步驟2: 將散熱片和風扇零件放置於CPU上方,調整方向使風扇電纜最靠近CPU風扇連接
器,參照示意圖之順序將螺絲鎖入,完成散熱片風扇的安裝。
»
請務必連接CPU風扇接頭
»
請參照CPU靜熱片的安裝手冊獲取正確的安裝訊

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Biostar A320MH 2.0 and is the answer not in the manual?

Biostar A320MH 2.0 Specifications

General IconGeneral
Form FactorMicro ATX
ChipsetAMD A320
CPU SocketAM4
Memory TypeDDR4
Memory Slots2
Maximum Memory32GB
PCIe Slots1 x PCIe 3.0 x16, 2 x PCIe 2.0 x1
LANRealtek RTL8111H Gigabit LAN
SATA Ports4
M.2 Slots1 x M.2
USB Ports6 x USB 2.0
Video OutputsHDMI, VGA
AudioRealtek ALC887 8-Channel HD Audio
