Biostar A58MD User Manual

A58MD/A58MG/A58ML
9
B. Memory Capacity
DIMM Socket Location
DDR3 Module
Total Memory Size
DDR3_A1 512MB/1GB/2GB/4GB/8GB/16GB
DDR3_B1 512MB/1GB/2GB/4GB/8GB/16GB
Max is 32GB.
C. Dual Channel Memory Installation
Please refer to the following requirements to activate Dual Channel function:
Install memory module of the same density in pairs, shown in the table.
Dual Channel Status DDR3_A1 DDR3_B1
Disabled O X
Disabled X O
Enabled O O
(O means memory installed, X means memory not installed.)
Note: The DRAM bus width of the memory module must be the same (x8 or x16)

Biostar A58MD Specifications

General

Socket	FM2+
Chipset	AMD A58
Memory Slots	2 x DIMM
Maximum Memory	32GB
Form Factor	Micro ATX
Storage Interface	4 x SATA 3Gb/s
Audio	Realtek ALC662
LAN	Realtek RTL8111G
Expansion Slots	1 x PCI
Memory Standard	DDR3
Video Outputs	VGA
USB Ports	4 x USB 2.0
