Biostar A58MD User Manual

Motherboard Manual
2
1.3 Motherboard Specifications
Specifications
CPU Support
Socket FM2+/FM2 for AMD A-series processor
Maximum CPU TDP (Thermal Design Power): 100Watt
* Please refer to www.biostar.com.tw
for CPU support list.
Chipset AMD A58/A55 FCH
Memory
Supports Dual Channel DDR3 800/ 1066/ 1333/ 1600/ 1866/ 2133/ 2400(OC)/
2600(OC)
2 x DDR3 DIMM Memory Slot, Max. Supports up to 32 GB Memory
Each DIMM supports non-ECC 512MB/ 1/ 2/ 4/ 8/ 16 GB DDR3 module
* Please refer to www.biostar.com.tw
for Memory support list.
Storage
AMD A58/A55 FCH
4x SATA 3Gb/s Connector
Supports RAID 0,1,10 & AHCI
LAN
Realtek RTL 8111G (A58MD, A58MG)
10/ 100/ 1000 Mb/s auto negotiation, Half / Full duplex capability
Realtek RTL 8106E (A58ML)
10/ 100 Mb/s auto negotiation, Half / Full duplex capability
Audio Codec
ALC662
5.1 Channels, High Definition Audio
USB
AMD A58/A55 FCH
8x USB 2.0 port (4 on rear I/Os and 4 via internal headers)
Expansion Slots
1x PCIe x1 Slot
1x PCIe 3.0 x16 Slot (Only FM2+ processors can support PCIe 3.0.)
Rear I/Os
1x PS/2 Mouse
1x PS/2 Keyboard
1x VGA Port
1x DVI Port (A58MD)
1x LAN port
4x USB 2.0 Port
3x Audio Jack
Internal I/Os
4x SATA 3.0Gb/s Connector
2x USB 2.0 Header (each header supports 2 USB 2.0 ports)
1x 4-Pin Power Connector
1x 24-Pin Power Connector
1x CPU Fan Connector
1x System Fan Connector
1x Front Panel Header
1x Front Audio Header
1x Clear CMOS Header
1x Serial Port Header
1x Chassis Speaker Header
Form Factor microATX Form Factor, 218 mm x 174 mm
OS Support
Windows XP / 7 / 8 / 8.1
Biostar reserves the right to add or remove support for any OS with or without
notice.

Biostar A58MD Specifications

General

Socket	FM2+
Chipset	AMD A58
Memory Slots	2 x DIMM
Maximum Memory	32GB
Form Factor	Micro ATX
Storage Interface	4 x SATA 3Gb/s
Audio	Realtek ALC662
LAN	Realtek RTL8111G
Expansion Slots	1 x PCI
Memory Standard	DDR3
Video Outputs	VGA
USB Ports	4 x USB 2.0
