Biostar A58MD User Manual

Motherboard Manual
20
6. Select the proper BIOS file, and a
message asking if you are sure to
flash the BIOS file. Click Yes to start
updating BIOS.
7. A dialog pops out after BIOS flash is
completed, asking you to restart the
system. Press the [Y] key to restart
system.
8. While the system boots up and the full screen logo shows up, press
<Delete> key to enter BIOS setup.
After entering the BIOS setup, please go to the Save & Exit, using the Restore
Defaults function to load Optimized Defaults, and select Save Changes and
Reset to restart the computer. Then, the BIOS Update is completed.

Biostar A58MD Specifications

General

Socket	FM2+
Chipset	AMD A58
Memory Slots	2 x DIMM
Maximum Memory	32GB
Form Factor	Micro ATX
Storage Interface	4 x SATA 3Gb/s
Audio	Realtek ALC662
LAN	Realtek RTL8111G
Expansion Slots	1 x PCI
Memory Standard	DDR3
Video Outputs	VGA
USB Ports	4 x USB 2.0
