第二章: 硬體安裝 | 9
B450MX / B450MX-S
<類型B>
步驟1: 取下主板上的散熱片和風扇零件支架,並保留散熱風扇的鐵背板於主板下方。
步驟2: 將散熱片和風扇零件放置於CPU上方,調整方向使風扇電纜最靠近CPU風扇連接
器,參照示意圖之順序將螺絲鎖入,完成散熱片風扇的安裝。
»
請務必連接CPU風扇接頭
»
請參照CPU靜熱片的安裝手冊獲取正確的安裝訊

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Biostar B450MX and is the answer not in the manual?

Biostar B450MX Specifications

General IconGeneral
Processor socketSocket AM4
Processor manufacturerAMD
Compatible processor seriesAMD Athlon, AMD Ryzen 3, AMD Ryzen 3 2nd Gen, AMD Ryzen 5, AMD Ryzen 7, AMD Ryzen 9 3rd Gen
Maximum number of SMP processors1
Audio chipRealtek ALC887
Component forPC
Motherboard chipsetAMD B450
PC health monitoringCPU, FAN, Temperature, Voltage
Audio output channels7.1 channels
Motherboard form factormicro ATX
Windows operating systems supportedWindows 10 x64, Windows 7 x64
Memory channelsDual-channel
Memory slots typeDIMM
Number of memory slots4
Supported memory typesDDR4-SDRAM
Maximum internal memory128 GB
Supported memory clock speeds4066, 1866, 2133, 2400, 2667, 2933, 3200, 3600, 4000, 4133, 4200, 4266, 4333 MHz
HDCPYes
DirectX version12.0
Parallel processing technology support-
USB 2.0 connectors2
USB 3.2 Gen 2 (3.1 Gen 2) connectors0
RAID levels0, 1, 10
Supported storage drive typesHDD & SSD
Supported storage drive interfacesM.2, SATA III
Wi-FiNo
LAN controllerRealtek RTL8111H
Ethernet interface typeGigabit Ethernet
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Cables includedSATA
Bundled softwareBullGuard
Harmonized System (HS) code84733020
Weight and Dimensions IconWeight and Dimensions
Depth244 mm
