24 | Chapter 4: Useful help
Chapter 4: Useful help
4.1 Driver Installation
Aer you installed your operang system, please insert the Fully Setup Driver DVD into your
opcal drive and install the driver for beer system performance.
You will see the following window aer you insert the DVD
The setup guide will auto detect your motherboard and operang system.
A. Driver Installaon
To install the driver, please click on the Driver icon. The setup guide will list the compable
driver for your motherboard and operang system. Click on each device driver to launch the
installaon program.
B. Soware Installaon
To install the soware, please click on the Soware icon. The setup guide will list the soware
available for your system, click on each soware tle to launch the installaon program.
C. Manual
Aside from the paperback manual, we also provide manual in the Driver DVD. Click on the
Manual icon to browse for available manual.
Note
»
 Ifthiswindowdidn’tshowupaeryouinserttheDriverDVD,pleaseuselebrowsertolocateand
executetheleSETUP.EXEunderyouropcaldrive.
»
 YouwillneedAcrobatReadertoopenthemanualle.PleasedownloadthelatestversionofAcrobat
Readersowarefromhp://get.adobe.com/reader/

»
Themotherboardusedintheillustraonsmaynotresembletheactualboard.theseillustraonsare
forreferenceonly.

Biostar B450NH Specifications

General

Processor socket	Socket AM4
Processor manufacturer	AMD
Compatible processor series	AMD Athlon, AMD Ryzen 3, AMD Ryzen 3 2nd Gen, AMD Ryzen 3 3rd Gen, AMD Ryzen 5, AMD Ryzen 5 2nd Gen, AMD Ryzen 5 3rd Gen, AMD Ryzen 5 5th Gen, AMD Ryzen 7, AMD Ryzen 7 2nd Gen, AMD Ryzen 7 3rd Gen, AMD Ryzen 7 5th Gen, AMD Ryzen 9 3rd Gen, AMD Ryzen 9 5th Gen
Processor thermal power (max)	105 W
Maximum number of SMP processors	1
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	1866, 2133, 2400, 2667 MHz
RAID levels	0, 1, 10
Supported storage drive interfaces	M.2, NVMe, PCI Express 3.0, SATA III
HDCP	Yes
DirectX version	12.0
Parallel processing technology support	Not supported
Number of SATA III connectors	4
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
Headphone outputs	3
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi	No
LAN controller	Realtek RTL8111H
Ethernet interface type	Gigabit Ethernet
BIOS type	UEFI
Audio chip	Realtek ALC887
Component for	PC
Motherboard chipset	AMD B450
Audio output channels	7.1 channels
Motherboard form factor	mini ATX
Windows operating systems supported	Windows 10 x64, Windows 11 x64, Windows 7 x64

Weight and Dimensions

Width	170 mm
