챕터 2: 하드웨어 설치 | 15
B450NH
확장 카드 설치
다음의 단계에 따라 확장 카드를 장착할 수 있습니다 :
에 확장 카를 설기 전에 확장 카드의 안문을 읽으시기 바랍.
에서 케스 커버, 볼트, 슬롯 브라켓을 제거.
확장 슬롯에 카를 놓고, 슬롯에 완게 장착이 되록 카를 아래로 눌
줍니다.
드의 금속 브라을 케이스 후면 패에 드라이를 이용하여 고.(
계는 VGA 카드 설만 해.
터 케스 커를 다시 덮.
한 경, 컴를 켜고 확장 카드 관련한 바이오스 설을 변합니.
확장 카드 관련 드라를 설.
»
를 설나 제거하려면 M2 타입 드라이버를 사용해야합니. 사양에 맞지 않는
드라버는 사용지 않는 것이 좋습다 나가 손상었을 수 있
2�6 점퍼 & 스위치 설정
아래의 일러스트는 어떻게 점퍼를 설정하는지 보여주고 있습니다. 점퍼 캡이 핀 위에
있으면 “닫힌 상태”이며, 그렇지 않으면 “열린 상태”입니다.
Pin opened Pin closed Pin 1-2 closed
JCMOS1: CMOS 클리어 점퍼
점퍼는 사용자에게 바이오스 안전 설정과 CMOS 데이터를 복구할 수 있게
합니다.메인보드가 손상되지 않도록 다음의절차를 준수하시기 바랍니다.
핀1-2 열림: 정상 작동 (기본값)
핀1-2 닫힘: CMOS 데이터 클리어
