1.3 MOTHERBOARD FEATURES
SPEC
CPU
LGA 775
Intel Core2Duo / Core2Quad /
Pent ium Dual-Core / Celeron Du al-Core /
Celeron 4xx processor
(Maximum Watt: 95W)
Supports Hyper-Threading / Execute Disable Bit /
Enhanced Intel SpeedStep® / Int el Archit ecture-64 /
Extended Memory 64 Technology / Virtualization
Technology
FSB
Support 800 / 1066 / 1333 MHz
Chipset
Intel G41
Inte l ICH7
Super I/O
ITE 8718F
Provides the most commonly used legacy
Super I/O functionality.
Low Pin Count Interface
Environment Control init iatives,
Hardware Monitor Controller
Fan Sp eed Contro ller
ITE's "Smart Guardian " funct ion
Main
Memory
DIMM Slots x 2
Each DIMM supports 256MB / 512MB /
1GB / 2GB DDR3
Max Memory Capacity 4GB
Dual Channel Mode DDR3 memory module
Supports DDR3 800/1066/1333(OC)
Registered DIMM and ECC DIMM is not supported
(CPU with FSB 800 MHz only supports DDR3 800)
Graphics
GMA X4500 Max Shared Video Memory is 256MB
IDE
Integr ated IDE Contro ller
Ultra DMA 33 / 66 / 100 Bus Master Mode
supports PIO Mode 0~4
SATA 2
Integrated Serial ATA Controller
Data transfer rates up to 3.0 Gb/s.
SATA Version 2.0 specif icat ion co mp liant
LAN
Realtek RTL 8102EL
10 / 100 Mb/s auto negotiation
Half / Full duplex capability
Sound
Codec
ALC662 / VT1708B
5.1 channels audio out
High Definition Audio
PCI slot x2 Supports PCI expansion cards
Slots
PCI Express x 16 slot x1 Supports PCI-E x16 expansion cards
Floppy Connector x1 Each connector supports 2 Floppy drives
Printer Port Connector x1 Each connector supports 1 Printer port
Serial port Connector x1 Connects to RS-232 Port
IDE Connector x1 Each connector supports 2 IDE device
On Board
Connectors
SATA Connector x4 Each connector supports 1 SATA devices
To Next Page
