Motherboard Manual
4
1.5 MOTHERBOARD LAYOUT
KBMS1
ATXPWR2
CPU_FAN1
JUSBV1
VGA1
USB1
RJ45USB1
AUDIO1
LAN
Super
I/O
Codec
FDD1
J_PRINT1
J_ COM 1
PCI1
PCI2
PEX16_ 1
BATTERY
BIOS
SYS_ FAN1
JUSBV 2
PANEL1 JCMOS1
F _U SB2
F_USB1
SATA1 SATA2
SATA3
SATA4
Intel
ICH7
IDE1
ATXPWR1
DDR3_B1
DDR3_A1
Intel
G41
F_AUDIO 1
LGA775
CPU1
Note: ■ represents the 1
st
pin.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Biostar G41D3 - SET UP and is the answer not in the manual?

Biostar G41D3 - SET UP Specifications

General IconGeneral
Form FactorMicro ATX
ChipsetIntel G41
CPU SocketLGA 775
Memory TypeDDR3
Memory Slots2
Maximum Memory8 GB
Integrated GraphicsIntel GMA X4500
Storage Interface4 x SATA 3Gb/s
Power Connector24-pin ATX, 4-pin ATX 12V
Video Outputs1 x VGA
Expansion Slots1 x PCIe x16
USB Ports8 x USB 2.0
AudioRealtek ALC662 6-Channel
LANRealtek
