Biostar G41D3 User Manual

G41D3+/G41D3G+ BIOS Manual
30
PCIE Frequency Setting
This item allows you to select the PCIE clock control
Options: 100 (Default) / Min=100; Max=150
CPU Voltage
This item allows you to select CPU Voltage Control.
FS B Voltage
This item allows you to select FSB Voltage Control.
Memory Voltage
This item allows you to select Memory Voltage Control.
Chipset Voltage
This item allows you to select Chipset Voltage Control.
DRAM Frequency
This item allows you to control the Memory Clock.
Options: Auto (Default) / DDR3 800
Configure DRAM Timing by SPD
Options: Enabled (Default) / Disabled
DRAM tCL
Options: 6 (Default) / 3 ~ 10
DR AM t RAS
Options: 15 (Default) / 9 ~ 24
DRAM tRP
Options: 6 (Default) / 3 ~ 10

Biostar G41D3 Specifications

General

Form Factor	Micro ATX
Chipset	Intel G41
CPU Socket	LGA 775
Memory Type	DDR3
Maximum Memory	8 GB
Storage Interface	4 x SATA 3Gb/s
USB Ports	8 x USB 2.0 (4 rear, 4 via headers)
Audio	Realtek ALC662 6-Channel HD Audio
CPU Support	Intel Core 2 Quad, Core 2 Duo, Pentium Dual-Core, Celeron
Memory Slots	2 x DIMM
Memory Speed	1066/800 MHz
Expansion Slots	1 x PCIe x16, 1 x PCI
Rear Panel I/O Ports	1 x PS/2 keyboard, 1 x PS/2 mouse, 1 x VGA, 4 x USB 2.0, 1 x RJ-45 LAN, 3 x audio jacks
