1.5 MOTHERBOARD LAYOUT
ATXPWR2
VGA1
USB1
RJ45USB1
AUDIO1
F_AUDIO1
JUSBV1
KBMS1
Super
I/O
LAN
Codec
CPU_FAN1
J_PRINT1
J_COM1
SYS_ FAN1
JUSBV2
PA N E L 1
JCMOS1
F_U SB2
F_USB1
SATA1 SATA2
SATA3
SATA4
PCI1
PCI2
PEX16_1
ID E1
ATXPWR1
DDR3_B1 DDR3_A1
BIOS
Intel
G41
Intel
ICH7
BAT1
LGA775
CPU1
JSPDIFOUT1
Note: ■ represents the 1
st
pin.
